Product Description
90-MIBDK0-G0EAY00Z | ASUS | Sabertooth X58 Desktop Motherboard INTEL Chipset Atx Socket B LGa-1366 24Gb Ddr3 Sdram Serial Ata/600, Serial Ata/300 Yes 7.1Product Details
Product Videos
Custom Field
Form Factor ATX
CPU Socket Type LGA 1366
Supported CPU(s) Intel Core i7 Processor
Intel Core i7 Processor Extreme Edition
Chipset Intel X58 Express
South Bridge Chipset Intel ICH10R
Number of Memory Slot(s) 6
Number of Memory Channel(s) 3
Supported Memory Standard(s) PC3-10600 (DDR3-1333)
PC3-12800 (DDR3-1600)
PC3-14900 (DDR3-1866)
PC3-8500 (DDR3-1066)
Maximum Installed Memory 24 GB
Expansion Slots PCI-E 2.0 x16
PCI-E x1
PCI-E x16
Expansion Slots Details 2 x PCIe 2.0 x16 (dual x16)
1 x PCIe x16 (x4 mode)
2 x PCIe x1
1 x PCI
Storage Controller Details Intel ICH10R controller
6 x SATA 3Gb/s port(s), black
Support Raid 0, 1, 5, 10
Marvell PCIe 9128 controller : *1
2 x SATA 6Gb/s port(s), gray
JMicron JMB362 controller
1 x Power eSATA 3Gb/s port(s), green
1 x eSATA 3Gb/s port(s), red
Network Gigabit Ethernet
Connectors/Ports 8-pin 12V Power Connector
Audio-In
Audio-Out
Chassis Fan Connector
CPU Fan Connector
PS/2 Keyboard
PS/2 Mouse
RJ-45
USB 2.0
Connectors/Ports Details Back I/O Ports
1 x PS/2 keyboard/mouse combo port(s)
1 x eSATA 3Gb/s
1 x Power eSATA 3Gb/s
1 x IEEE 1394a
1 x LAN (RJ45) port(s)
6 x USB 2.0
1 x Optical S/PDIF out
6 x Audio jack(s)
Internal I/O Ports
3 x USB 2.0 connector(s) support(s) additional 6
