X9SCI-LN4 | SUPERMICRO | Atx INTEL C204/Xeon E3-1200/Core I3/Pentium/Celeron Ddr3 LGa-1155 MotherboardProduct Details
Product Videos
Custom Field
Form Factor ATX
CPU Socket Type LGA 1155
Supported CPU(s) Intel Celeron Processor
Intel Pentium Processor
Supported CPU Technologies 64-bit
AES New Instructions
Demand Based Switching
Enhanced Intel Speedstep Technology
Execute Disable Bit
Hyper-Threading Technology
Idle States
Intel 64 Architecture
Intel Trusted Execution Technology
Intel Turbo Boost Technology
Intel Virtualizati
Chipset Intel C204
Number of Memory Slot(s) 4
Supported Memory Standard(s) PC3-10600 (DDR3-1333)
PC3-12800 (DDR3-1600)
Maximum Installed Memory 32GB
Expansion Slots PCI Express x16
Expansion Slots Details 1 (x16) PCI-E 3.0 slot
1 PCI 32-bit slot
Storage Controller Serial-ATA 3.0 Gbps
Serial-ATA 6.0 Gbps
Storage Controller Details 6x SATA ports total (4x 3Gb, 2x 6Gb)
On-Board Video Controller BMC integrated Matrox G200
Network Gigabit Ethernet
Connectors/Ports RJ-45 (Ethernet)
USB 2.0
Connectors/Ports Details 4x RJ45 Gigabit Ethernet LAN ports
8x USB 2.0 ports total
(2x rear + 6x via header)
1x VGA port
2x Fast UART 16550 serial port
(one header and one rear port)
1x DOM (Disk on Module) power connector
1x TPM Header
